Panel 4K ULTRA HD / OLED with Absolute Black Filter
Screen Resolution 3,840 (W) x 2,160 (H)
Panel Drive OLED Superb Motion Drive
Picture Mode Dynamic/Normal/Cinema/True Cinema/THX 4K (Cinema/Bright Room)/Custom/Professional Photo/Professional1/Professional2 (isfccc)/Sport/Game/DolbyVision (Vivid/Bright/Dark)
Ultra HD Premium*1 TBD
Muti HDR Support*2 HDR10+/HDR10/HLG/DolbyVision/HLG Photo*15
HDR Brightness Enhancer Y
Dynamic HDR Effect Y
Contrast Ultimate Contrast
Colour Space Wide Colour Spectrum
HCX Processor HCX Pro Intelligent Processor
THX Certified Display*3 Y (TBD)
isf Mode Y
Dolby Atmos Y
Surround Cinema Suround Pro
Speaker Output 50 W (10 W x 2 + 15 W x 2)
Sound Mode Standard/Music/Speech/Stadium/User
Smart TV my Home Screen4.0
Voice Personal Assistan Y (TBD)
On Screen Display Menu Languages 27 Languages*16
Voice Guidance Y
Digital TV DVB-T/T2/DVB-S2/DVB-C
Twin Tuner Y
Wireless LAN Built-in Y
Panasonic TV Remote Apps Y
Swipe & Share Y
TV Anywhere*4 Y
In-House TV Streaming (DVB-IP) Y (Server / Client)
Media Player Media Player Y (2.0)*17
Support Format AVI/HEVC/MKV/WMV/MP4/M4v/FLV/3GPP/VRO/VOB/TS/PS, MP3/AAC/WMA Pro/FLAC/Apple Lossless/WAV, JPEG/HLG Photo
Web Browser*5 Y
Mirroring Y(Easy Mirroring)
Teletext Reception 2000P
Home Network*6 Y (Server / Client)
Multi Window 2T PAP/PIP/PAT
Bluetooth*7 Y/HID / HOGP (Keyboard/Mouse)/A2DP (Audio In/Out)
HDAVI Control Y
Bluetooth Audio Link*8 Y
IP Home Control Y (TBD)
Data Broadcasting Hbb TV
USB-HDD Recording *9 Y (w/ Rewind live TV)
Ambient Sensor (CATS) Y
Digital Tuner Reception DVB-T/T2/DVB-S2/DVB-C
Analogue Tuner Y
HDMI (4K 60/50p with HDCP2.2) 4
Support Feature Audio Return Channel (Input 2)
Support Feature HDMI2.1 Auto low ratency mode
HDMI*12 2 (side), 2 (rear)
USB 3 (1 side, 2 rear; USB 3.0 x 1, USB 2.0 x 2)
CI (Common Interface) 2 (CI Plus, Version 1.4, ECP)
Component Video Input shared with Composite RCA phono type x 1 (rear)
Digital Audio Output (Optical) 1 (rear)
Headphone Output 1 (side; switchable to Subwoofer)
Dimensions (W x H x D) (w/o stand) 1,228 x 713 x 62 mm
VESA Compatible Y
VESA Dimension 400 x 300 mm
Dimensions (W x H x D) (with stand)*14 1,228 x 774 x 300 mm
NOTE *1 Ultra HD PremiumTM logo is a trademark of the UHD Alliance, Inc.
NOTE *2 All models Supporting HDR does not increase the peak brightness capabilities of the TV panel.
NOTE Full HD & HD models The ability to send a non 4K HDR signal via HDMI depends fully on the playback device. The majority of 4K Blu-ray discs require HDCP2.2 on TV to play back HDR, whereas the HDMI input on this TV support only HDCP1.4; accordingly not all HDR contents are guaranteed to be enjoyed on the TV.
NOTE *3 THX and the THX logo are trademarks of THX Ltd. which are registered in some jurisdictions. The THX 3D logo is a trademark of THX Ltd. All rights reserved.
NOTE *4 Due to network conditions or certain broadcaster restrictions, this function may not be available.
NOTE *6 The Web Browser cannot display some web pages correctly. And viewable contents by the Web Browser are subject to the following conditions;
NOTE viewable contents may vary depend on models,
NOTE viewable contents may differ from those for PC,
NOTE viewable contents may be limited.
NOTE *7 File formats that are not supported by your Network Contents server (DLNA compatible server, etc.) cannot be played.
NOTE *8 The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license.
NOTE *9 When a Bluetooth device is connected to the TV, it is possible that the Bluetooth audio output may not be synchronized (i.e. be delayed) with relation to the images on the screen. This is not a defect of the TV or the device. The delay time will differ depending on the device.
NOTE *10 This feature requires a USB hard drive or flash drive with a capacity of at least 160 GB.
NOTE *13 The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries.
NOTE *15 Dimension with recommended pedestal style.
NOTE *16 27 Languages (English / German / Italian / Spanish / French / Danish /Finnish / Swedish / Dutch / Hungarian / Czech / Romanian / Bulgarian / Polish / Norwegian / Estonian / Latvian / Lithuanian / Portuguese / Turkish / Greek / Croatian / Slovak / Slovenian / Serbian / Russian / Macedonian)
NOTE *17 To playback HDR, a HDR source is required (H.264 or H.265(ST2084 or HLG format)).
