Panel 4K ULTRA HD/Master OLED HDR with Absolute Black Filter
Bright Panel Ultra Bright Panel
Screen Resolution 3,840 (W) x 2,160 (H)
Panel Drive OLED Superb Motion Drive
Picture Mode Dynamic/Normal/Cinema/True Cinema/THX 4K (Cinema/Bright Room)/Custom/Professional Photo/Professional1/Professional2 (isfccc)/Sport/Game
Ultra HD Premium*1 Y
HDR Brightness Enhancer (auto/manual) Y
Muti HDR Support*15 HDR10+ certified, HDR10, HLG
Contrast Ultimate Contrast
Colour Space Wide Colour Spectrum
HCX Processor Y
THX Certified Display*2 Y
isf Mode Y
Surround Cinema Surround Pro
Speaker Output 40 W (10 W x 2 + 10 W x 2)
Sound Mode Standard/Music/Speech/Stadium/User
my Home Screen Y (3.0)
Voice Assistant Y
Voice Guidance Y
On Screen Display Menu Languages 27 Languages*13
Twin HD Tuner / HD Triple Tuner Y / Y
Unique Processing Engine Quad-Core Pro
Wireless LAN Built-in Y
Panasonic Media Center (App) Y
TV Anywhere*3 Y
In-House TV Streaming Y (Server / Client)
Panasonic TV Remote Apps Y
Swipe & Share Y
Smart Calibration Y
Web Browser*4 Y
Internet Apps*16 Y
Easy Mirroring Y
DLNA*5 Y (DTCP-IP/DMP/DMR/DMS)
Bluetooth*6 Y (Keyboard/Mouse/Audio Device)
IP Home Control (Crestron/Control4) Y
Media Player Y (2.0)*14
Support Format AVCHD/Progressive, AVI/HEVC/MKV/WMV/MP4/M4v/FLV/3GPP/VRO/VOB/TS/PS, MP3/AAC/WMA Pro/FLAC/Apple Lossless/WAV, JPEG
Bluetooth Audio Link*17 Y
Teletext Reception 2000P
USB-HDD Recording (w/ Rewind live TV)*7 Y
Multi Window 2T PAP/PIP/PAT
HDAVI Control Y
Screen Resolution 3,840 (W) x 2,160 (H)
Ambient Sensor (CATS) Y
Digital Tuner Reception DVB-T/T2/DVB-S2/DVB-C
Analogue Tuner Y
HDMI*10 2 (side), 2 (rear)
HDMI (4K 60/50p with HDCP2.2) 4
Support Feature Audio Return Channel (Input 2)
USB 3 (1 side, 2 rear; USB 3.0 x 1, USB 2.0 x 2)
LAN Port 1
CI (Common Interface) 2 (CI Plus, Version 1.4)
SD Card Y
Component Video Input shared with Composite RCA phono type x 1 (rear)
Digital Audio Output (Optical) 1 (rear)
Headphone Output 1 (side)
Dimensions (W x H x D) (w/o stand) 1449 x 837 x 62 mm
Dimensions (W x H x D) (with stand)*12 1449 x 898 x 300 mm
Weight (w/o stand) 28.0 kg
Weight (with stand) 33.5 kg
VESA Compatible Y
VESA Dimension 400 x 400 mm
NOTE*1 Ultra HD PremiumTM logo is a trademark of the UHD Alliance, Inc.
NOTE*2 THX and the THX logo are trademarks of THX Ltd. which are registered in some jurisdictions. The THX 3D logo is a trademark of THX Ltd. All rights reserved.
NOTE*3 Due to network conditions or certain broadcaster restrictions, this function may not be available.
NOTE*4 The Web Browser cannot display some web pages correctly. And viewable contents by the Web Browser are subject to the following conditions;
NOTE - viewable contents may vary depend on models,
NOTE - viewable contents may differ from those for PC,
NOTE - viewable contents may be limited.
NOTE*5 DLNA, the DLNA Logo and DLNA CERTIFIED are trademarks, service marks, or certification marks of the Digital Living Network Alliance.
NOTE*6 HID (Human Interface Device Profile) compliant keyboards are available. A2DP (Advanced Audio Distribution Profile) compliant audio devices are available. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license.
NOTE*7 This feature requires a USB hard drive or flash drive with a capacity of at least 160 GB.
NOTE*8 Based on IEC 62087 Ed.2 measurement method.
NOTE*9 Energy consumption XYZ kWh per year, based on the power consumption of the television operating 4 hours per day for 365 days. The actual energy consumption will depend on how the television is used.
NOTE*10 The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries.
NOTE*11 Not all the accessories are listed here.
NOTE*12 Dimension with recommended pedestal style.
NOTE*13 27 Languages (English / German / Italian / Spanish / French / Danish /Finnish / Swedish / Dutch / Hungarian / Czech / Romanian / Bulgarian / Polish / Norwegian / Estonian / Latvian / Lithuanian / Portuguese / Turkish / Greek / Croatian / Slovak / Slovenian / Serbian / Russian / Macedonian)
NOTE*14 To playback HDR, a HDR source is required (H.264 or H.265(ST2084 or HLG format)).
NOTE*15 All models Supporting HDR does not increase the peak brightness capabilities of the TV panel.
NOTE Full HD & HD models The ability to send a non 4K HDR signal via HDMI depends fully on the playback device. The majority of 4K Blu-ray discs require HDCP2.2 on TV to play back HDR, whereas the HDMI input on this TV support only HDCP1.4; accordingly not all HDR contents are guaranteed to be enjoyed on the TV.
NOTE*16 Internet apps are provided by their respective service providers, and may be changed, interrupted, or discontinued at any time. Panasonic assumes no responsibility and makes no warranty for the availability or the continuity of the services.
NOTE*17 When a Bluetooth device is connected to the TV, it is possible that the Bluetooth audio output may not be synchronized (i.e. be delayed) with relation to the images on the screen. This is not a defect of the TV or the device. The delay time will differ depending on the device.
