Panel OLED Professional Edition
Screen Resolution 3,840 (W) x 2,160 (H)
Panel Drive OLED Superb Motion Drive
Ultra HD Premium*1 TBD
Muti HDR Support*2 HDR10+, HDR10, HLG, DolbyVision, HSP(HLG Photo)
HDR Brightness Enhancer Y
Contrast Ultimate Contrast
Colour Space Wide Colour Spectrum
HCX Processor HCX Pro Intelligent Processor
THX Certified Display*3 Y (TBD)
isf Mode Y
Dolby Atmos Y
Speaker Output 140 W (40 W x 2 + 20 W x 3)
Smart TV my Home Screen4.0
Voice Personal Assistant Voice Personal Assistant Y (TBD)
Voice Guidance Y
On Screen Display Menu Languages 27 Languages*16
Digital TV DVB-T/T2/DVB-S2/DVB-C
Twin Tuner Y
Wireless LAN Built-in Y
Panasonic TV Remote Apps Y
Swipe & Share Y
TV Anywhere Y
In-House TV Streaming (DVB-IP) Y (Server / Client)
Web Browser*6 Y
Easy Mirroring Y
Bluetooth*8 HID / HOGP (Keyboard/Mouse)
Bluetooth*8 A2DP (Audio In/Out)
Network Contents Playback *7 Y (Server / Client)
Bluetooth Audio Link*9 Y
Media Player Y (2.0)*17
Teletext Reception 2000P
USB-HDD Recording *10 Y(w/ Rewind live TV)
Multi Window 2T PAP/PIP/PAT
HDAVI Control Y
IP Home Control Y (TBD)
Data Broadcasting Hbb TV
Digital Tuner Reception DVB-T/T2/DVB-S2/DVB-C
Analogue Tuner Y
HDMI*13 2 (side), 2 (rear)
HDMI (4K 60/50p with HDCP2.2) 4
Support Feature Audio Return Channel (Input 2)
Support Feature HDMI2.1 Auto low ratency mode
USB 3 (1 side, 2 rear; USB 3.0 x 1, USB 2.0 x 2)
CI (Common Interface) 2 (CI Plus, Version 1.4, ECP)
Component Video Input shared with Composite RCA phono type x 1 (rear)
Digital Audio Output (Optical) 1 (rear)
Headphone Output 1 (side switchable to Subwoofer)
Dimensions (W x H x D) (w/o stand) 1,446 x 885 x 78
Dimensions (W x H x D) (with stand)*15 1,446 x 907 x 310
VESA Compatible Y
NOTE *1 Ultra HD PremiumTM logo is a trademark of the UHD Alliance, Inc.
NOTE *2 All models Supporting HDR does not increase the peak brightness capabilities of the TV panel.
NOTE Full HD & HD models The ability to send a non 4K HDR signal via HDMI depends fully on the playback device. The majority of 4K Blu-ray discs require HDCP2.2 on TV to play back HDR, whereas the HDMI input on this TV support only HDCP1.4; accordingly not all HDR contents are guaranteed to be enjoyed on the TV.
NOTE *3 THX and the THX logo are trademarks of THX Ltd. which are registered in some jurisdictions. The THX 3D logo is a trademark of THX Ltd. All rights reserved.
NOTE *4 Due to network conditions or certain broadcaster restrictions, this function may not be available.
NOTE *6 The Web Browser cannot display some web pages correctly. And viewable contents by the Web Browser are subject to the following conditions;
NOTE viewable contents may vary depend on models,
NOTE viewable contents may differ from those for PC,
NOTE viewable contents may be limited.
NOTE *7 File formats that are not supported by your Network Contents server (DLNA compatible server, etc.) cannot be played.
NOTE *8 The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license.
NOTE *9 When a Bluetooth device is connected to the TV, it is possible that the Bluetooth audio output may not be synchronized (i.e. be delayed) with relation to the images on the screen. This is not a defect of the TV or the device. The delay time will differ depending on the device.
NOTE *10 This feature requires a USB hard drive or flash drive with a capacity of at least 160 GB.
NOTE *13 The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries.
NOTE *15 Dimension with recommended pedestal style.
NOTE *16 27 Languages (English / German / Italian / Spanish / French / Danish /Finnish / Swedish / Dutch / Hungarian / Czech / Romanian / Bulgarian / Polish / Norwegian / Estonian / Latvian / Lithuanian / Portuguese / Turkish / Greek / Croatian / Slovak / Slovenian / Serbian / Russian / Macedonian)
NOTE *17 To playback HDR, a HDR source is required (H.264 or H.265(ST2084 or HLG format)).
