Amp Type Stereo Amp
RMS Output Power (AC Power Supply) 20W (1 kHz, THD 10%, 6O)
RMS Output Power (Battery Supply) 12W (1 kHz, THD 10%, 6O)
Type 1 way, 1 speaker system
Unit 8cm Full Range x 2
Bass Expand Bass Reflex Port
Playback Disc *¹ CD-R / RW
Format CD-DA / MP3
Mecha.Type 1CD (Top-Open Type)
USB Play / Rec.*² No
FM 30 stations
Radio Data System No
Auto Tuning Yes
Antenna Built-in (min. 180 - max. 823mm)
Super Sound EQ, Super Bass Sound Sound Booster
USB Port Yes (For Service Use and Customer Software Update)
Display Size (View area) 45 x 15.9 mm
Type LCD (Union Jack) without Backlight
Preset Keys Yes (5 Direct Preset Keys on Main Set)
Handle Built-in Handle
Power Supply AC 220 - 240V, 50Hz
Power Consumption *³
Normal Use 14 W
Normal Standby 0.2 W
Auto OFF Yes
Language Indication Alphabet
Timer Function *4
Play Timer Yes
Battery Operation *4 LR14/ R14(C) x 8pcs
Dimensions (W x H x D) 346 x 130 x 239 mm
Without Battery 2.5 Kg (approximate)
With Battery 3.0 Kg (approximate)
AC Cord Yes (1.5 m)
Operating Instruction WEB OI
Note *1 Playability may vary depending on the contents, discs and quality of the recording.
*2 Only a USB flash drive. Playback is not possible from a portable device (Apple, Android, etc.) using a USB extension cable.
*3 Specifications are subject to change without notice. All numbers given here are approximate.
*4 Timer functions reset when there is a power failure or when the AC mains lead is removed.
*5 The unit cannot be turned on from the remote control when using batteries as the power source.
