Amp Type 2.1 ch Amp
RMS Output Power Front Speaker (Left/Right) 60 W x 2 (6 Ohm, 1kHz,10%THD)
Subwoofer 120 W (3 Ohm, 100Hz,10%THD)
Total RMS Stereo mode power 240 W
Bass Expand ass Reflex Port
Wireless Subwoofer Type 1 way, 1 speaker system(Bass reflex)
Bluetooth Version Bluetooth® Ver 4.1
Class Class 1
Connectivity Multi-Pairing(MAX 8 Devices)
Wi-Fi WLAN Standard IEEE802.11 a/b/g/n
Frequency Range 2.4GHz band / 5GHz band
Chromecast built-in Multi-room yes
Support Format HE-AAC, LC-AAC, MP3, CELT, Opus, Vorbis, WAV, FLAC
Music Streaming App *1 iOS yes (Bluetooth)
Android yes (Bluetooth)
Surround Virtual Surround
SOUND MODE STANDARD, MUSIC, CINEMA, VOICE, NEWS
Subwoofer Level Adjustment yes
Dolby Digital / Dolby Digital + / Dolby True HD yes/-/-
DTS / DTS ES / DTS 96/24 yes/-/-
HDMI FUNCTION CEC yes
Audio Return Channel(for HDMI Output)*3 yes
Battery Charge no promote (500 mA)
USB Port for Service Use yes
USB Port for Customer Software Update yes
USB Port x 1 (Service Use Only)
HDMI Output x 1 (ARC)
Audio Input Optical Digital Input yes
MAIN UNIT SETTING
Wall Mountable yes
Auto OFF yes
Main Unit Dimensions (W x H x D) 853 x 60.5 x 90 mm
Weight 1.9 kg
Wireless Subwoofer Dimensions (W x H x D) 185 x 303 x 337 mm
Weight 4.8 kg
*1 Download on the App Store. Download on Google Play?.
*2 Enabled by software update.
*3 Package Remarks ARC (Audio Return Channel) compatible TV is required.
*4 Specifications are subject to change without notice. All numbers given here are approximate.
REMARKS Consider world wide design, except USA. For example, for Taiwan market and wide-range power supplier design.
