Output Channel 3.1ch
Power Output - Home Theater Mode (RMS)Total Power 300W
Front 60W/ch (1kHz, 6ohms, 10% THD)
Center 60W (1kHz, 6ohms, 10% THD)
Subwoofer 120W (100Hz, 3ohms, 10% THD)
Dolby Digital yes
DTS Digital Surround yes
SMART NETWORKING & EASY OPERATION
Bluetooth® Wireless Technology yes
Panasonic Music Streaming App yes*3
Wireless Subwoofer yes
ARC (Audio Return Channel) yes*6
HDMI Output yes(TV)
Optical Digital Audio Input yes(TV)
Front Speaker Dimensions (W x H x D) 853 x 60.5 x 90 mm
Weight 2.3 kg
Subwoofer Dimensions (W x H x D) 185 x 303 x 337 mm
Weight 4.3 kg
NOTE*1 Party Mode; playing a single sound source simultaneously through multiple speakers. The maximum number of speakers is limited (Under study).
NOTE*2 Multi Zone; playing each of multiple songs within the same network to separate speakers. The maximum number of sound sources is limited (Under study).
NOTE When using a subscription service, this function depends on the conditions of the service provider (Under study).
NOTE*3 Download on the App Store. Download on Google Play?.
NOTE*4 To use NFC without downloading App, an OS Version 4.1 or later AndroidTM device is required.
NOTE The installation of the Panasonic Music Streaming App allows use of an Android smartphone or tablet with the NFC function and OS Version 4.1 or earlier.
NOTE*5 When you use the app ?Panasonic Music Streaming? to stream music on this system to other AllPlay speakers
NOTE The video and audio output may not be synchronised during playback of video contents.
NOTE If music is streamed to other AllPlay speakers for more than 8 hours, the other AllPlay speakers will
NOTE automatically stop playing the music. (The specifications are subject to change without notice.)
NOTE*6 ARC compatible TV is required.
NOTE*7 The other connected devices have to be turned off. Standby (Bluetooth standby on) power consumption approximately 3.0W(HTB885/ ALL70T/ HTB690), 2.0W (HTB688/HTB488/494/498).
NOTE*8 Standby (Wireless Link is not activated) power consumption approximately 0.4W(HTB885), 1.0W(ALL70T/HTB690).
NOTE Specifications are subject to change without notice. All numbers given here are approximate.
