Output Channel 2ch
Power Output (RMS) Total Power 20W
Front 10W (1kHz, 6ohms, 10% THD)
USB Slot yes (x1)
USB Standard USB 2.0 Full Speed
HIGH QUALITY SOUND
Full Digital Amplifier System yes
Bluetooth® Re-Master yes
Preset EQ 4 (Heavy, Soft, Clear, Vocal) + Flat
XBS Master yes
Bluetooth® Wireless Technology. yes
Panasonic Music Streaming App*2 yes
Band/ Station Presets FM/ 30
Auto Tuning yes
Auto Power Off/ Dimmer yes/ yes
Programmable Timer Sleep / Clock / Play Timer
Remote Control yes
Main Unit Dimensions (W x H x D) [Approx.] 184 x 123 x 228 mm*7
Weight [Approx.] 1.1 kg*7
Front Speaker Dimensions (W x H x D) [Approx.] 139 x 224 x 136 mm*7
Weight [Approx.] 1.3 kg*7
NOTE*1 Only a USB flash drive. Playback is not possible from a portable device (Apple, Android, etc.) using a USB extension cable.
NOTE*2 Download on the App Store. Download on Google Play?.
NOTE*3 Not all models are compatible. See dealer for details.
NOTE*4 When you use the app "Panasonic Music Streaming" to stream music on this system to other AllPlay speakers
NOTE The video and audio output may not be synchronised during playback of video contents.
NOTE If music is streamed to other AllPlay speakers for more than 8 hours, the other AllPlay speakers will automatically stop playing the music. (The specifications are subject to change without notice.)
NOTE*5 DSD 5.6MHz files can be played on this unit only. (5.6MHz files can not re-stream to other units.)
NOTE*6 Standby (Bluetooth standby on) power consumption approximately 0.5W (PMX150/PMX152), 0.45W (PMX80/PMX82/PMX84/PMX82M), 0.4W (PM600/602), 0.3W (PM250/250B)
NOTE*7 Weight and dimensions are approximate.
NOTE Playability may vary depending on the contents, discs and quality of the recording. For contents recorded for your personal use.
NOTE Specifications are subject to change without notice. All numbers given here are approximate.
