Output Channel 2ch
Power Output (RMS) Total Power 120W
Front 60W (1kHz, 3ohms, 10% THD)
USB Slot yes (x2)
USB Standard USB 2.0 High Speed
Playback MP3, AIFF, AAC, FLAC (up to 192kHz/24bit), WAV (up to 192kHz/24bit), DSD (5.6MHz/2.8MHz)
Band/Station Presets FM/ 30, DAB Plus/ 20
Auto Tuning yes
Multi-room Audio with Qualcomm® Allplay? yes
Wireless LAN System yes
Home Network Music Playback yes
Wi-Fi Frequency Range yes (5GHz/ 2.4GHz)
Ethernet (10 Base-T/ 100 Base-TX) yes
WPS Support yes
Bluetooth® Wireless Technology yes
Panasonic Music Streaming App yes*2
USB Connection for iPod/ iPad/ iPhone yes (Playback/ Charging)*3
Re-streaming (Bluetooth®, CD, Radio, USB Memory, USB-DAC, AUX)*4*5 yes
Net Preset Button (for Internet Radio) yes (Main Unit & Remote Control)
Number of Preset 6.0
HIGH QUALITY SOUND
Full Digital Amplifier System yes
LincsD-Amp yes (3rd generation)
VGDA (Variable Gain Digital Amplifier) yes
Virtual Battery Power Supply yes
Built-in Power Conditioner yes
USB-DAC Function MP3, AIFF, FLAC (up to 192kHz/24bit), WAV (up to 192kHz/24bit), DSD (5.6MHz/2.8MHz)
XBS Master yes
CD High-Res Re-Master yes
MP3 Re-Master yes
Bluetooth® Re-Master yes
Super Sonic Tweeter yes
Bamboo Plant Opal Cone yes (Woofer)
Preset EQ 4 (Heavy, Soft, Clear, Vocal) + Flat
Bass & Treble Control yes (Knob on main unit)
LAN Terminal yes
Analogue Audio Input (AUX) Pin Jack yes
Headphone Output yes
Auto Power Off/ Dimmer yes/ yes
Programmable Timer Sleep / Clock / Play Timer
Remote Control yes
DIMENSIONS, WEIGHT Main Unit(W x H x D) 211 x 114 x 267 mm *7
Weight 3.0 kg *7
Weight 3.0 kg *7
Front Speaker(W x H x D) 161 x 238 x 264 mm *7
NOTE*1 Only a USB flash drive. Playback is not possible from a portable device (Apple, Android, etc.) using a USB extension cable.
NOTE*2 Download on the App Store. Download on Google Play?.
NOTE*3 Not all models are compatible. See dealer for details.
NOTE*4 When you use the app "Panasonic Music Streaming" to stream music on this system to other AllPlay speakers
NOTE The video and audio output may not be synchronised during playback of video contents.
NOTE If music is streamed to other AllPlay speakers for more than 8 hours, the other AllPlay speakers will automatically stop playing the music. (The specifications are subject to change without notice.)
NOTE*5 DSD 5.6MHz files can be played on this unit only. (5.6MHz files can not re-stream to other units.)
NOTE*6 Standby (Bluetooth standby on) power consumption approximately 0.5W (PMX150/PMX152), 0.45W (PMX80/PMX82/PMX84/PMX82M), 0.4W (PM600/602), 0.3W (PM250/250B)
NOTE*7 Weight and dimensions are approximate.
NOTE Playability may vary depending on the contents, discs and quality of the recording. For contents recorded for your personal use.
NOTE Specifications are subject to change without notice. All numbers given here are approximate.
